| 额定载荷 Rated Load | 0.1， 0.2，0.3，0.5，1，2,3，5，7，10，20 (kN)
|
| 综合精度 Comprehensive Precision | 0.5%F·S |
| 灵敏度 Sensitivity | 1.0～1.5 mV/V |
| 蠕变 Creep | ±0.05 %F·S/30min |
| 零点输出 Zero Output | ±1 %F·S |
| 零点温度影响 Temperature Effect On Zero | ±0.05 %F·S/10℃ |
| 输出温度影响 Temperature Effect On Output | ±0.05 %F·S/10℃ |
| 工作温度 Operating Temperature Range | -20℃～+65℃ |
| 输入阻抗 Input Resistance | 350±20 Ω |
| 输出阻抗 Output Resistance | 350±3 Ω |
| 绝缘电阻 Insulation Resistance | >5000 MΩ |
| 安全过载 Safe Load Limit | 150% F·S |
| 供桥电压 Bridge Voltage | 建议 10V DC |
| 材质 Material | 不锈钢
Stainless Steel |
传感器接线方式
Load Cell Mode of Connection | 输入+:红 Input+: Red
输入-:黑 Input-:Black
输出+:绿 Output+:Green
输出-:白 Output-:White
|
