额定载荷RatedLoad | 100～500 (kN） |
综合精度ComprehensivePrecision | 0.02～0.05%F·S |
灵敏度Sensitivity | 2.0 mV/V |
蠕变Creep | 士0.02%F·S/30min |
零点输出ZeroOutput | ±1%F·S |
零点温度影响TemperatureEffect OnZero | +0.02%F·S/10℃ |
输出温度影响TemperatureEffect OnOutput | ±0.029%F·S/10℃ |
工作温度OperatingTemperatureRange | -20℃~+65℃ |
输入阻抗Input Resistance | 750±15Ω |
输出阻抗Output Resistance | 700±5Ω |
绝缘电阻Insulation Resistance | >5000 MΩ |
安全过载SafeLoadLimit | 150%F·S |
供桥电压BridgeVoltage | 建议10V DC |
材质Material | 合金钢Alloy Steel |
传感器接线方式 LoadCellModeof Connection | 输入+:红 Input+: Red 输入-:黑 Input-: Black 输出+:绿 Output+:Green 输出-; Output-; Whit |
